ACME THREAD GAUGES

ACME Threads are used for translation motion in machine tools like lead screws, where rapid movement is required or in screw jacks, where load to be shared is more

Specification

American Specifications	ANSI/ ASME B1.5- 1997
B.S Specifications	B.S 1104 – 1957

Manufacturing range

• Thread Plugs , Thread Rings, Check Plugs & Wear Check Plugs of Diameter from 1/4″ to 8″ and TPI from 16 to 3.
